OpenTofu Foundations: Advanced State Management with OpenTofu (Part 9)

In this webinar, we'll look at advanced strategies for using and manipulating the statefile. If you work with OpenTofu (or Terraform) long enough, you will have to repair, modify, or recover state. Guaranteed.

by:  Chris Hill

Share

This is part 9 of a 10 week workshop. Check out part 8 or watch the recorded session here.

Prerequisites

• Completion of Week 8: Understanding State Management

Remote State

Context

We've taken the modules for our database (DB) and EC2 instance and removed the root module that ties them together. This is a common pattern you may see, especially in situations where you have a shared resource, such as a network or a database. Unless you organize your OpenTofu modules in a single monolith, you'll need to pass references to other resources. This can be done via values, but another option is the terraform_remote_state data source, which allows you to reference the outputs of another remote module.

Steps

1. Navigate to the database module directory and deploy it:

   cd code/aws_db_instance
   tofu init
   tofu apply


2. While it runs, examine the aws_instance module code:

   • It now takes variables for database info, using those variables to generate user_data.

3. Consider the problem of securely providing database details like the password:

   • Options include command-line input, prompting, or .tfvars files, all of which have issues.
     • command line is error prone, requires users to have sensitive values, and stores sensistive values in command history
     • using the prompts is very error prone, requires users to have sensitive values, and doesn't work in automation
     • using a .tfvars file will likely require the file (and sensitive values) to be checked into source control
   • Instead, use the terraform_remote_state to securely fetch only the necessary outputs.

4. Add a terraform_remote_state block to reference the state:

   data "terraform_remote_state" "db" {
     backend = "local"
     config = {
       path = "../aws_db_instance/terraform.tfstate"
     }
   }

   locals {
     user_data = <<-EOF
                 #!/bin/bash
                 yum update -y
                 amazon-linux-extras install docker -y
                 service docker start
                 usermod -a -G docker ec2-user
                 docker run -d \
                   -e WORDPRESS_DB_HOST=${data.terraform_remote_state.db.outputs.endpoint} \
                   -e WORDPRESS_DB_USER=${data.terraform_remote_state.db.outputs.username} \
                   -e WORDPRESS_DB_PASSWORD=${data.terraform_remote_state.db.outputs.password} \
                   -e WORDPRESS_DB_NAME=${data.terraform_remote_state.db.outputs.db_name} \
                   -p 80:80 ${var.image.name}:${var.image.tag}
               EOF
   }


5. Deploy the aws_instance module

   cd ../aws_instance
   tofu init
   tofu apply


Drawbacks of Remote State

• Security: State files contain all resource data. OpenTofu only allows you to use outputs, but you will need read access to the entire file.
• Hidden Monolith: Dependencies between modules are one-sided, making them hidden to the module being referenced.
• Immutability Issues: Deleting and/or modifying outputs can break referencing modules.

Import Resources

Context

You might encounter scenarios where:

1. Existing resources (created via the console, cloud CLI/SDK or other tools) need to be managed with OpenTofu.
2. State files are lost or corrupted.

This section will demonstrate how you can import existing resources into your OpenTofu state file.

Import Process

1. Change directory into the aws_db_instance module.

   cd ../aws_db_instance


2. Rename or remove the statefile.

   mv .terraform.tfstate .terraform.tfstate.old


3. Use tofu import to add a security group back into the state file:

   tofu import aws_security_group.this <security_group_id>


4. Use the declarative import block for the database instance:

   import {
     to = aws_db_instance.this
     id = var.name_prefix
   }


5. Comment out the aws_vpc_security_group_ingress_rule and aws_vpc_security_group_egress_rule. We'll deal with them a little differently.

6. Apply:

   tofu apply


Code Generation for Complex Resources

We're going to demonstrate the code generation feature on the security group rules.

1. Add import blocks with known IDs:

   import {
     to = aws_vpc_security_group_ingress_rule.http
     id = <security group rule id>
   }

   import {
     to = aws_vpc_security_group_egress_rule.http
     id = <security group rule id>
   }


2. Generate code with:

   tofu plan -generate-config-out=security_groups.tf


3. Review and refine the generated file as needed before applying. You can keep the new file (and delete the commented out rules) or delete the generated file.

4. Apply:

   tofu apply


Moving and Renaming Resources

Context

Refactoring often involves renaming resources or restructuring modules. OpenTofu may interpret these changes as deletion and recreation unless explicitly directed.

Renaming Resources

1. Change directory into the aws_instance module.

   cd ../aws_instance


2. Change the resource name of the aws_instance from this to webserver in your configuration:

   resource "aws_instance" "webserver" {
     # configuration
   }


3. Move the resource in the state file. You may also need to update outputs:

   tofu state mv aws_instance.this[0] aws_instance.webserver[0]
   tofu apply


Restructuring Counts or Loops

For changes like removing count:

1. Update the configuration.

   resource "aws_instance" "webserver" {
     //count = 1
     ...
   }


2. Run:

   tofu state mv aws_instance.webserver[0] aws_instance.webserver
   tofu apply


Migrating Resources to New Types

Context

Resource deprecation or provider updates may require migrating resources to newer types. For example, replacing aws_security_group_rule with aws_vpc_security_group_ingress_rule.

Steps

1. Update the resource configuration:

   resource "aws_vpc_security_group_ingress_rule" "http" {
     security_group_id = aws_security_group.this.id
     from_port         = 80
     to_port           = 80
     ip_protocol       = "tcp"
     cidr_ipv4         = "0.0.0.0/0"
   }

   resource "aws_vpc_security_group_egress_rule" "all" {
     security_group_id = aws_security_group.this.id

     ip_protocol = "-1"
     cidr_ipv4   = "0.0.0.0/0"
   }


2. Remove the old resource from state:

   tofu state rm aws_security_group_rule.http_ingress
   tofu state rm aws_security_group_rule.all_egress


3. Import the new resource:

   tofu import aws_vpc_security_group_ingress_rule.http <id>
   tofu import aws_vpc_security_group_egress_rule.all <id>


4. Apply changes:

   tofu apply


Conclusion

By mastering these advanced state management techniques, you can:

• Reference remote state securely.
• Recover and manage resources via imports.
• Refactor and migrate resources efficiently.

These tools are essential for maintaining robust and scalable infrastructure with OpenTofu.
